When it comes to finding the best budget-friendly flight controller (FC) and electronic speed controller (ESC) stack for FPV drones, the SpeedyBee F405 V4 and the iFlight BLITZ ATF435 are top contenders. Both offer excellent performance at a great price, but which one stands out as the best option? Let’s dive into the details and find out.
New to FPV? Check out our comprehensive flight controller buyer’s guide: https://oscarliang.com/flight-controller/
Table of Contents
Where to Buy
Get the SpeedyBee F405 V4 here:
- AliExpress: https://s.click.aliexpress.com/e/_DFU9NkF
- RDQ: https://oscarliang.com/product-6ro8
- GetFPV: https://oscarliang.com/product-bc57
- Amazon: https://amzn.to/46EzYZi
- FPV24: https://oscarliang.com/product-nqbg
- Speedybee: https://oscarliang.com/product-wncw
Get the iFlight BLITZ ATF435 here:
Differences and Similarities Between These Stacks
The iFlight BLITZ ATF435 is $9 cheaper than the SpeedyBee F405 V4, but price alone doesn’t tell the whole story. Let’s compare the two to see which stack offers the best value for your money.
For a deeper dive into the SpeedyBee F405 V4, check out my full review: https://oscarliang.com/speedybee-f405-v4/
Flight Controller
Processor and Sensors
The iFlight BLITZ ATF435 uses the AT32 chip, which helps keep costs down. Learn more about AT32: https://oscarliang.com/at32-flight-controllers/.
The AT32F435 MCU offers performance close to the STM32F722 at a much lower price. While the AT32F435 supports 8K looptime and DShot600, and the SpeedyBee F405 supports 4K looptime and DShot300, the difference in real-world flight performance is minimal.
Both stacks use the ICM42688 Gyro, so they are comparable in terms of noise performance and ease of tuning.
Both stacks feature built-in barometers and support i2c connections (SDA and SCL) for a compass, And they are both compatible with Betaflight and iNav firmware.
Features and Specs
Both stacks offer 6 UARTs, more than enough for most FPV pilots. Typically, you’ll only need 2 to 4 UARTs for peripherals like a radio receiver, GPS, digital VTX OSD, and SmartAudio (and ESC telemetry and camera control but these are rarely used nowadays).
The BLITZ FC features an onboard 32MB memory chip for Blackbox logging, offering around 20 minutes of flight data. In contrast, the SpeedyBee uses a micro SD card slot for Blackbox, which requires an micro SD card that would cost another $10.
The SpeedyBee F405 V4 has 8 motor outputs, while the iFlight BLITZ has only 4. This gives the SpeedyBee more versatility for complex builds like hexacopters or octocopters.
The SpeedyBee also has a built-in Bluetooth module, allowing you to wirelessly configure Betaflight settings via the SpeedyBee App on your phone—a feature not available on the BLITZ. You can however use an OTG cable to connect to your Android phone.
Solder Pads and Connectors
One of the standout features of the BLITZ is the size and spacing of the solder pads. They’re large with plenty of separations, making soldering a breeze even for beginners. The silkscreen labels are clear, and the layout is intuitive, with pads organized in two rows on each edge. The SpeedyBee pads are slightly smaller and closer together but still relatively easy to work with.
Most FC only has one single LED pad, but the Speedybee has LED strip pads at each corner, making LED light connection super easy.
On the BLITZ FC, there are some JST connectors on the bottom of the board for various peripherals like receiver, GPS and LED/Buzzer etc. However, the board lacks a standard connector for digital VTXs, requiring either a split connector or direct soldering. On the other hand, the Speedybee offers a standard connector for digital VTX such as the DJI O3, but for all other devices you’d have to direct solder. Both stacks have onboard AT7456E chip, and they support analog FPV system.
BEC
Both flight controllers include two voltage regulators (BEC): 5V and 9V. The Blitz offers 5V at up to 2.5A and 9V at 2A. The 5V output is more than sufficient to power various devices, including an ExpressLRS receiver and a few LED strips. The 9V regulator should handle most VTXs, though the DJI O3 Air Unit, which can draw up to 16W (1.8A at 9V), is close to the limit. In such cases, powering the VTX directly from the battery might be a better option. The 5V and 9V BECs in the Speedybee have a higher rating at 3A each, making them more reliable and capable of supporting more power-hungry devices.
4in1 ESC
Both brands use a 55A BLHeli_S ESC in their stacks. Performance and features are similar, with both being compatible with Bluejay firmware and equipped with onboard current sensors.
Despite having a similar current rating, the Speedybee 4in1 ESC includes a heatsink for cooling and protection. However, this adds about 10 grams of weight, which may not be a significant issue for typical 5″ FPV freestyle and racing drones, but could be a consideration if you’re building an ultralight drone where saving weight is crucial.
Another notable difference is the input voltage: the Speedybee supports 3S to 6S, while the Blitz supports 2S to 6S. For most users running 4S or 6S setups, both stacks will work perfectly fine.
The BLITZ ESC features tabs at each corner for soldering motor wires, which can make for a tidier setup, though it might be challenging to fit the ESC into some tight frames.
Which Stack Should You Get?
Both stacks will serve most people well if you’re building a typical FPV drone—whether it’s a 5″ or 7″ quadcopter running on a 4S or 6S LiPo/Li-ion battery, which are the most common setups today for freestyle, racing, cinematic, or long-range applications. Your choice between these stacks may ultimately come down to brand preference and price differences.
However, certain scenarios may call for choosing one stack over the other:
Who Should Choose the iFlight BLITZ ATF435:
- If you’re looking for the cheapest possible FC/ESC stack, the iFlight BLITZ ATF435 is $9 cheaper, and you won’t need to spend extra on an SD card for Blackbox logging.
- If you’re aiming for the lightest possible build, the Blitz stack is about 10g lighter than the Speedybee F405 V4.
- If you plan to power your quad with a 2S LiPo battery.
- If you prefer a solderless setup, the JST connectors on the bottom of the Blitz stack can be very helpful.
Get the iFlight BLITZ ATF435 here:
Who Should Choose the Speedybee F405 V4:
- If you are a beginner, Speedybee offers much better documentations and wiring diagrams. Also it has a much larger user base so you are more likely to get help from someone who have used this stack.
- If you need more versatility and flexibility in your setup.
- The 8 motor outputs allow for hexacopter and octocopter configurations.
- If you want to connect servos for head tracking, the extra motor outputs can be very useful.
- If you plan to install LED light strips on each arm, the Speedybee’s LED and 5V pads at each corner make wiring easier, and the 5V 3A BEC can support more LEDs.
- The built-in Bluetooth allows for wireless Betaflight configuration via your phone.
Get the Speedybee F405 V4 here:
- AliExpress: https://s.click.aliexpress.com/e/_DFU9NkF
- RDQ: https://oscarliang.com/product-6ro8
- GetFPV: https://oscarliang.com/product-bc57
- Amazon: https://amzn.to/46EzYZi
- FPV24: https://oscarliang.com/product-nqbg
- Speedybee: https://oscarliang.com/product-wncw
How About Flywoo F722 V2 and GEPRC Taker Stacks?
Flywoo and GEPRC also offer budget FC/ESC stacks, and while they have their pros and cons, I personally think Speedybee and BLITZ have an edge over them.
For instance, the Flywoo stack is $15 more expensive than the Speedybee, but it features the good old MPU6000 gyro, which may be a compelling selling point for some. However, the JST connectors and solder pads make it harder to build and repair, which puts me off. Otherwise, it’s a decent stack. For more details, check out my review: https://oscarliang.com/flywoo-goku-f722-v2-fc-stack/
The GEPRC Taker stack is similarly priced to the Speedybee, but its small solder pad and connector location impact the user experience. It also lacks various features that the Speedybee F405 V4 offers. See my review for more info: https://oscarliang.com/geprc-taker-f405/
Conclusion
Both the SpeedyBee F405 V4 and the iFlight BLITZ ATF435 are excellent choices for budget FPV builds, each with its strengths. Your decision should be based on your specific needs and preferences, whether you prioritize cost, weight, or versatility. Either way, you’re getting a quality stack that delivers great performance without breaking the bank.
